ZSW series of linear vibrating screen dual motor drive High efficiency

Linear vibrating screen

ZSW series of linear vibrating screen is widely applied to the screening of dry materials in ore dressing, building material, water and power and light industry.

Features:

Simple structure; it is easy to replace the screen

High wear resistance, low noise

High screening efficiency, low energy consumption

ZSW series of linear vibrating screen is widely applied to the screening of dry materials in ore dressing, building material, water and power and light industry. The advantages of this series of screening machine include stable operation, lower energy consumption, low noise, high efficiency and long service life.

Features and Advantages of LK Series Linear Vibrating

1. High vibrating force with unique eccentric structure. The adopt advanced structure makes the vibrating force powerful;

2. The beam and case of the screen are connected with high strength bolts without welding;

3. Simple structure, easy to repair;

4. Adopting tire coupling and soft connection ensures operation smooth;

5. High efficiency, easy maintenance and sturdy and durable use.

Working Principle of Linear Vibrating Screen

Linear vibrating screen adopts dual motor drive. When the motors do synchronous and reverse rotation, the exciting forces generated by eccentric block cancel each other out on the parallel direction of motor axis, and stack together with the direction that perpendicular to the motor axis, so its trajectory is a straight line. There is a dip on the two motor's relative screen surface, materials are tossed by leaps and bounds forward for linear motion under the exciting force and the self-gravity of the materials so as to achieve the purpose of screening and grading.

Technical Parameters of Linear Vibrating Screen
